<strong>335N-36</strong>

335N-36

Automatic Door Bottom



Brand:
Brands
Categories: , , Brand:

FEATURES

  • Aluminum frame with black neoprene seal
  • Flame and moisture resistant
  • Sound reducing
  • Smoke and draft control
  • Mounts inside prepared mortise: 5⁄8 x 19⁄16” (16 x 40mm)
  • Use with a threshold for maximum sealing capability
  • Nylon brush for carpet applications or no threshold provided
  • Maximum drop: 3⁄4” (19 mm)
  • For temperatures -62°C to 135°C (-81°F to 275°F)
  • End caps are included
  • Available in 36” (914 mm) lengths
  • Other lengths available

Visit National Guard Products (ngp.com) for more details

DOCUMENTATION

Product Page

downloadA600-NGP (Flyer)

Disclaimer
  • We recommend that physical hardware be ordered and verified before starting any preparation, manufacturing or installation work.
  • All product installations must be done by qualified personnel using the proper mounting hardware for the appropriate surface or material.
  • We recommend that installers and manufacturers use the instructions inside the packaging provided by the manufacturer, as the manufacturer reserves the right to make technical changes, modify product or information without prior notice.
  • Do not exceed the maximum weight or dimensions recommended by the manufacturer.
  • All technical documents, drawings and instructions are provided as-is. Customers (primary or secondary) cannot derive any claim based on the use of these documents. No responsibility is or will be assumed.
