ABH-A570HD
FULL SURFACE

Brand:

Categories: BHMA Products, Geared Hinges, Hinges, Matte Black Products

FEATURES

Certified ANSI/BHMA A156.26, Grade 1
cULus fire rated, 90/60 min.*
Full surface, heavy duty
¹⁄₁₆″ (1.6 mm) door inset
For narrow-faced frames, ⁷⁄₈″ (22mm) minimum frame width
48″ (1219 mm) door width maximum
450 lbs. door weight maximum
Undercut machine screws and sex-bolts included

*Metal door / wood door

FINISHES

B
BLACK ANODIZED

C
CLEAR ANODIZED

D
DARK BRONZE ANODIZED

DOCUMENTATION

Product Page
04.201
BHMA Products Guide

Disclaimer

We recommend that physical hardware be ordered and verified before starting any preparation, manufacturing or installation work.
All product installations must be done by qualified personnel using the proper mounting hardware for the appropriate surface or material.
We recommend that installers and manufacturers use the instructions inside the packaging provided by the manufacturer, as the manufacturer reserves the right to make technical changes, modify product or information without prior notice.
Do not exceed the maximum weight or dimensions recommended by the manufacturer.
All technical documents, drawings and instructions are provided as-is. Customers (primary or secondary) cannot derive any claim based on the use of these documents. No responsibility is or will be assumed.
