<strong>DGS-SB12S</strong></br> ADHESIVE GASKETING
NEW

DGS-SB12S
ADHESIVE GASKETING



Brand:
Brands
Categories: , , Brand:

FEATURES

  • cULus listed (UL10C)
    – Wood fire door: 20 min
    – Composite fire door: 90 min
    – Metal fire door: 3 hrs
  • Silicone gasket with permanent adhesive strip
  • Surface mounted
  • For use on wood or metal door frames
  • Compresses to fill gaps between 1⁄16  - 1⁄4”  (2 – 6 mm)
  • Provides an excellent general-purpose seal
  • Extruded high-temperature silicone, self-extinguishing and non-toxic
  • Effective between -50 to 232°C (-58  to 450°F)
  • Impervious to fungus, mold, and mildew
  • Unaffected by sunlight, ozone, and ultraviolet rays
  • Coil length of 17ft (50.8cm) is sufficient for a door frame for a 3 x 7ft (91.4 x 213.4cm) door
  • Can be cut to required length
  • Other lengths available by special order

DOCUMENTATION

Product Page

download06.253
downloadDGS Flyer

Installation Instructions

downloadDGS-SB12S – Installation Instructions

Disclaimer
  • We recommend that physical hardware be ordered and verified before starting any preparation, manufacturing or installation work.
  • All product installations must be done by qualified personnel using the proper mounting hardware for the appropriate surface or material.
  • We recommend that installers and manufacturers use the instructions inside the packaging provided by the manufacturer, as the manufacturer reserves the right to make technical changes, modify product or information without prior notice.
  • Do not exceed the maximum weight or dimensions recommended by the manufacturer.
  • All technical documents, drawings and instructions are provided as-is. Customers (primary or secondary) cannot derive any claim based on the use of these documents. No responsibility is or will be assumed.
