GX1 SERIES
ELECTRIFIED
GRADE 1

DOREX GX1 electrified door locks (GX1C-E, GX1L-E, GX1S-E) are designed for high traffic areas requiring heavy-duty locks with enhanced security features. Ideal for commercial areas such as office buildings, universities, industrial and institutional facilities.



Brand:
Brands
Categories: , , , Tags: , , , Brand:

FEATURES

  • Certified ANSI/BHMA A156.2, series 4000, Grade 1
  • cULus listed, 3 hr fire rating
  • ANSI/UL 10C Positive Pressure Rated
  • Meets ADA requirements
  • 10 Year limited mechanical warranty
  • 1 Year limited electronic warranty
  • For doors 13⁄8 to 2″ (35 to 51 mm) thick
  • Non-handed
  • 23⁄4″ (70 mm) backset
  • 23⁄8″, 33⁄4″ and 5″ (60 mm, 95 mm and 127 mm) backsets available
  • Stainless steel latch with 1⁄2″ (12.7 mm) throw
  • Deadlatch with 3⁄4″ (19 mm) throw available
  • Fixed security posts
  • Lever clutch release for damage prevention
  • Electrified options:
    – EL – Fail Safe (Power fails = Unlocked)
    – EL-RX – Fail Safe, Request to exit
    – EU – Fail Secure (Power fails = Locked)
    – EU-RX – Fail Secure, Request to exit
  • 39⁄16″ (90 mm) rose diameter
  • Concealed mounting plate and screws
  • ASA strike
  • Keyed functions include 6-pin cylinder, Schlage “C” profile with 2 keys
  • Small format interchangeable core (SFIC) model available (BEST-F® and CX5® cores sold separately)

Full keying services available. Other common and high security keyways available.

LEVER STYLES


GX1L Standard return

GX1S Straight; no return

GX1C Curved return

FUNCTIONS

80Storeroom keyed function

FINISHES

C26D
SATIN CHROME
C19
MATTE BLACK

Other finishes available
Approximate finish simulation, for reference only

DOCUMENTATION

Product Page

download01012N-E – GX1 Electrified Series (All Styles)
download01012N-2E – GX1L Electrified Series

Installation Instructions

downloadGX1-E (Electrified) Installation Instructions
downloadGX1L – SFIC Instructions
